DJI Mavic 3 Multispectral – Precision Drone for Agriculture & Environmental Monitoring
Discover hidden insights with the DJI Mavic 3 Multispectral, a cutting-edge drone engineered by the leader in drone technology. Designed for professionals in precision agriculture, environmental monitoring, and natural resource management, the Mavic 3 Multispectral combines advanced RGB and multispectral imaging, centimeter-level RTK positioning, and long flight times to deliver the data and accuracy your operations demand.
Powerful Dual Camera System: RGB + Multispectral
The Mavic 3 Multispectral features one 20MP 4/3 CMOS RGB camera paired with four 5MP multispectral cameras capturing green, red, red edge, and near-infrared bands. This powerful imaging system enables crystal-clear crop growth analysis and precise aerial surveying for agriculture, forestry, and environmental research.
Built-in Sunlight Sensor for Accurate NDVI
Equipped with a sunlight sensor, the drone records solar irradiance during flight, embedding it in image files. This ensures improved accuracy and consistency in NDVI calculations and 2D reconstructions, providing reliable data even across different lighting conditions and time periods.
Centimeter-Level RTK Positioning
With an integrated RTK module, the Mavic 3 Multispectral achieves centimeter-level positioning accuracy. The RTK module, flight control system, and cameras synchronize in microseconds, enabling precise location tagging for each image without the need for ground control points, making aerial surveys highly efficient and accurate.
Ultra-Long Flight Time and Fast Charging
The drone offers an impressive maximum flight time of up to 43 minutes, capable of covering up to 200 hectares in a single flight. Fast charging options include an 88W aircraft charger or a 100W Battery Charging Hub for multi-battery recharging, minimizing downtime between flights.
Reliable Transmission and Safety Features
Mavic 3 Multispectral supports DJI’s O3 transmission system, providing ultra-long transmission distances up to 15 kilometers with stable HD video feed. Omnidirectional obstacle sensing combined with terrain-follow mode ensures safe flights, even in complex terrain or steep slopes, by detecting obstacles in all directions.
Ideal Applications
The DJI Mavic 3 Multispectral is versatile for numerous agricultural and natural resource tasks such as orchard mapping, prescription mapping for croplands, intelligent field scouting, environmental monitoring, and natural resource surveys including water enrichment, forest distribution, and urban green space monitoring.
Technical Specifications
Aircraft
-
Weight: 951 g (including battery, propellers, RTK module, and microSD card)
-
Max Takeoff Weight: 1,050 g
-
Dimensions (Folded): 223 × 96.3 × 122.2 mm (without propellers)
-
Dimensions (Unfolded): 347.5 × 283 × 139.6 mm (without propellers)
-
Diagonal Length: 380.1 mm
-
Max Ascent Speed: 6 m/s (Normal), 8 m/s (Sport)
-
Max Descent Speed: 6 m/s (Normal & Sport)
-
Max Flight Speed: Normal 15 m/s; Sport forward 21 m/s, sideways 20 m/s, backward 19 m/s
-
Max Wind Resistance: 12 m/s
-
Max Takeoff Altitude: 6000 m
-
Max Flight Time: 43 minutes (at 36 kph, wind-free)
-
Max Hover Time: 37 minutes (hovering, sea level, wind-free)
-
Max Flight Distance: 32 km (at 57.6 kph, wind-free)
-
Max Tilt Angle: 30° (Normal), 35° (Sport)
-
Max Angular Velocity: 200°/s
-
GNSS: GPS + Galileo + BeiDou + GLONASS (GLONASS only with RTK)
-
Hovering Accuracy: Vertical ±0.1 m (Vision), ±0.5 m (GNSS), ±0.1 m (RTK); Horizontal ±0.3 m (Vision), ±0.5 m (HD), ±0.1 m (RTK)
-
Operating Temperature: -10°C to 40°C
RGB Camera
-
Sensor: 4/3 CMOS, 20 MP
-
Lens: FOV 84°, 24 mm equiv., f/2.8–f/11, focus 1 m to ∞
-
ISO Range: 100–6400
-
Shutter Speed: Electronic 8–1/8000 s; Mechanical 8–1/2000 s
-
Max Image Size: 5280 × 3956
-
Photo Modes: Single, Timelapse, Panorama
-
Video Resolutions: 4K 3840×2160@30fps; FHD 1920×1080@30fps
-
Max Bitrate: 130 Mbps (4K), 70 Mbps (FHD)
-
File Formats: JPEG/DNG (photo), MP4 (video)
Multispectral Camera
-
Sensor: 1/2.8" CMOS, 5 MP ×4 (Green, Red, Red Edge, Near IR)
-
Lens: FOV 73.91°, 25 mm equiv., f/2.0
-
Spectral Bands: Green 560 ± 16 nm, Red 650 ± 16 nm, Red Edge 730 ± 16 nm, NIR 860 ± 26 nm
-
Gain: 1x–32x
-
Shutter Speed: 1/30–1/12800 s
-
Max Image Size: 2592 × 1944
-
Photo Modes: Single, Timelapse
-
Video: FHD 1920 × 1080 @ 30fps
-
Video Content: NDVI, GNDVI, NDRE
-
File Formats: TIFF (photo), MP4 (video)
Transmission & Sensing
-
Transmission System: DJI O3 Industry Edition
-
Live View Quality: 1080p @ 30fps
-
Frequencies: 2.400–2.4835 GHz, 5.725–5.850 GHz (Note: 5.1/5.8GHz may be restricted locally)
-
Max Range (One-way): FCC 15 km; CE/SRRC/MIC 8 km (interference-free outdoor)
-
Download Speed: 15 MB/s
-
Latency: ~200 ms
-
Antennas: 4 (2 TX, 4 RX)
-
EIRP: 2.4 GHz <33 dBm (FCC), <20 dBm (others); 5.8 GHz <33 dBm (FCC), <14–30 dBm (others)
-
Obstacle Sensing: Omnidirectional with terrain-follow support
-
Vision Sensors FOV: Forward/Backward 90°×103°; Lateral 90°×85°; Upward 100°/90°; Downward 130°/160°
-
Max Detection Speed: Up to 15 m/s (direction-dependent)
Battery & Charging
-
Battery Type: LiPo 4S, Lithium Cobalt
-
Capacity: 5000 mAh, 15.4 V
-
Energy: 77 Wh
-
Weight: 335.5 g
-
Charging Temperature: 5°C to 40°C
-
Charger Input: 100–240V AC, 50/60Hz, 2.5A
-
Charger Output: Max 100W
-
Charging Hub: 3-battery rotation, USB-C input
Remote Controller (DJI RC Pro Enterprise)
-
Display: 5.5” 1080p, 60fps, 1000 nits
-
Transmission: DJI O3 Industry Edition
-
Wi-Fi: 802.11 a/b/g/n/ac/ax, 2x2 MIMO
-
Bluetooth: 5.1
-
Battery: 5000 mAh, 7.2 V, Li-ion; ~3 hours runtime
-
Charging Time: 1.5–2.5 hours (varies)
-
Storage: 64 GB internal + microSD slot
-
Ports: Mini-HDMI
-
Operating Temperature: -10°C to 40°C
RTK Module
-
Dimensions: 50.2 × 40.2 × 66.2 mm
-
Weight: 24 ± 2 g
-
Interface: USB-C
-
Power: ~1.2 W
-
Accuracy (Fixed RTK): Horizontal 1 cm + 1 ppm; Vertical 1.5 cm + 1 ppm
